162 6 way distribution blocks

Series 162 6 way distribution blocks



Approvals



Request STP/BIM File

Series 162KV compact distribution blocks are designed to be connected behind the transformer or within the installation, for distributing or branching to other fittings.

They are available in 6 way versions, with one port taken up by the incoming feed and 5 ports available for branch extensions.

Available in colours black or white.

Series 162SV cord sets comprise of a 162KV connector wired to a 7.5cm long cable, fitted witha standard 162STS connector.

All 6 ports are then available for branch extensions.

Items shown comply to low voltage regulations 73/23/EWG.

Data sheet

Material
polyamide 6.6 V2
Voltage
48v
Current Rating
25A
Operating Temperature
70°C

Specific References

Download

162 dist datasheet

Download (380.38KB)
