BESA

Available in 3, 4 and 6-pole versions, all 16A rated, they are manufactured in V0 self-extinguishing material. All BESA socket outlets use double stacked terminals for ease of installation, allowing for loop in and loop out, and can accommodate up to 2.5mm conductors.
The BESA range fits all standard round UK BESA / conduit boxes in plastic or metal and complies with BS5733:2010+A1:2014, while the plugs comply with BS EN 61535..

BESA

There are 7 products.

Showing 1-7 of 7 item(s)

Active filters

3 pole BESA Socket Outlet

The Metway 3 pole Besa socket outlet is designed to fit standard 'G' type industry preferred connectors

This fits straight onto standard round U.K plastic or metal besa/conduit boxes

Typical applications for this type of connector would be, any installation that has fire regulations insisting on mechanical containment of cabling with the building fabric (e.g where the use of conduit and conduit boxes is required

The easy fit and connect Besa box is supplied with fixing screw. It offers an easy loop in and out facilitated by double stacked terminal design on mounting plate connectors

Moulded in V0 grade plastic and rated at 16A, 230V AC +/- 10%, 50Hz with a terminal capacity of 2.5mm², this product is compliant with BS 733:2010+A1:2014 and the connectors to BS61535

4 pole BESA Socket Outlet

The Metway 4 pole Besa socket outlet is designed to fit standard 'G' type industry preferred connectors

This fits straight onto standard round U.K plastic or metal besa/conduit boxes

Typical applications for this type of connector would be, any installation that has fire regulations insisting on mechanical containment of cabling with the building fabric (e.g where the use of conduit and conduit boxes is required

The easy fit and connect Besa box is supplied with fixing screw. It offers an easy loop in and out facilitated by double stacked terminal design on mounting plate connectors

Moulded in V0 grade plastic and rated at 16A, 230V AC +/- 10%, 50Hz with a terminal capacity of 2.5mm², this product is compliant with BS 733:2010+A1:2014 and the connectors to BS61535

6 Pole BESA Socket Outlet

The Metway 6 pole Besa socket outlet is designed to fit standard 'G' type industry preferred connectors.

This fits straight onto standard round U.K plastic or metal besa/conduit boxes.

Typical applications for this type of connector would be, any installation that has fire regulations insisting on mechanical containment of cabling with the building fabric (e.g where the use of conduit and conduit boxes is required.

The easy fit and connect Besa box is supplied with fixing screw. It offers an easy loop in and out facilitated by double stacked terminal design on mounting plate connectors.

Moulded in V0 grade plastic and rated at 16A, 230V AC +/- 10%, 50Hz with a terminal capacity of 2.5mm², this product is compliant with BS 733:2010+A1:2014 and the connectors to BS61535.

3 Pole Besa Latching Leads

Our 3 pole Besa latching leads, are the mating part to our 3 pole Besa socket outlet. They are supplied with a 3-pole centre latching plug, to a free end using 1.00mm² LS0H cable. This can be supplied in lengths as per your requirements. These are supplied with a black industry standard, connector coding. Alternatively there is an option for white connectors.

4 Pole Besa Latching Leads

Our 4 pole Besa latching leads, are the mating part to our 4 pole Besa socket outlet. They are supplied with a 4-pole centre latching plug, to a free end using 1.00mm² LS0H cable. This can be supplied in lengths as per your requirements. These are supplied with a black industry standard, connector coding. Alternatively there is an option for white connectors.

6 Pole Besa Latching Leads

Our 6 pole Besa latching leads, are the mating part to our 6 pole Besa socket outlet. They are supplied with a 6-pole centre latching plug, to a free end using 1.00mm² LS0H cable. This can be supplied in lengths as per your requirements. These are supplied with a black/blue industry standard, connector coding. There is an option for white or red covers.

Besa Plugs

Our Besa plugs are the mating part to our Besa socket outlets. These are supplied with a black or white industry standard connector coding on 3 or 4 poles, and black/blue on the 6 pole (there is an option for black grey connectors also). There are alternative black and red (4 and 6 pole only) covers available.
